完成本培训课程后，学生将成功地证明他们能够： 创建新工程 使用 Vijeo Citect 与 I/O 设备通信 创建图形页面并操作图形符号 生成和管理报警、趋势和报表 排查和解决课程中遇到的问题 充分发挥 Vijeo Citect 应用程序的性能 有效使用 Vijeo Citect 联机帮助主题和知识库Vijeo Citect 配置培训课程是完整教育服务课程不可或缺的一部分。本课程面向下列用户： Vijeo Citect 新用户 以前没有 SCADA 经验的用户 SCADA 经验丰富的 Vijeo Citect 新用户，这类用户可将本课程作为了解Vijeo Citect 与其他 SCADA 产品之间差异的指南。
Citect培训手册V7.2 R2.pdf
(5.59 MB, 售价: 5 E币)
目录
第 1 章: VIJEO CITECT 简介 ..............................................................................1-1
概述............................................................................................................................1-1
课程概述....................................................................................................................1-2
课程开始前的准备工作............................................................................................1-5
本手册中使用的惯例................................................................................................1-6
第 2 章: VIJEO CITECT 配置环境 ......................................................................2-1
概述............................................................................................................................2-1
系统要求....................................................................................................................2-2
Citect 工程管理器.....................................................................................................2-5
包含工程....................................................................................................................2-6
Citect 工程编辑器.....................................................................................................2-7
Citect 图形编辑器.....................................................................................................2-8
Cicode 编辑器...........................................................................................................2-9
第 3 章: 工程管理................................................................................................3-1
概述............................................................................................................................3-1
新建工程....................................................................................................................3-2
集群和服务器............................................................................................................3-6
用户权限..................................................................................................................3-11
计算机设置向导......................................................................................................3-13
备份、恢复和删除工程..........................................................................................3-18
包含定制工程..........................................................................................................3-23
第 4 章: 通信........................................................................................................4-1
概述............................................................................................................................4-1
快速通信向导............................................................................................................4-2
通信对话框................................................................................................................4-9
变量标签..................................................................................................................4-11
视窗..........................................................................................................................4-13
测试通信..................................................................................................................4-14
结构化标签名称......................................................................................................4-24
使用 Microsoft Excel 添加变量标签 ....................................................................4-27
第 5 章: 图形........................................................................................................5-1
概述............................................................................................................................5-1
图形页面....................................................................................................................5-2
Tab_Style_Include 工程............................................................................................5-3iv 版本 7.20 2011 年 10 月
创建新页面................................................................................................................5-6
绘制基本对象............................................................................................................5-8
绘制巴氏灭菌器图形页面......................................................................................5-11
长方形、正方形、椭圆和圆..................................................................................5-14
管道、直线和连线..................................................................................................5-17
运行时属性..............................................................................................................5-19
自定义符号..............................................................................................................5-32
ActiveX.....................................................................................................................5-35
动态大小调整..........................................................................................................5-40
第 6 章: 操作员输入............................................................................................6-1
概述............................................................................................................................6-1
滑钮控制....................................................................................................................6-2
触击命令....................................................................................................................6-7
键盘命令..................................................................................................................6-10
第 7 章: 精灵........................................................................................................7-1
概述............................................................................................................................7-1
从库中粘贴精灵........................................................................................................7-2
自定义精灵................................................................................................................7-6
修改精灵....................................................................................................................7-7
精灵语法....................................................................................................................7-8
第 8 章: 弹出页面................................................................................................8-1
概述............................................................................................................................8-1
弹出页面....................................................................................................................8-2
结构化标签名称的优势............................................................................................8-9
第 9 章: 设备........................................................................................................9-1
概述............................................................................................................................9-1
什么是设备？ ............................................................................................................9-2
设置设备....................................................................................................................9-3
设备历史文件............................................................................................................9-4
第 10 章: 事件......................................................................................................10-1
概述..........................................................................................................................10-1
定义事件..................................................................................................................10-2
启用事件..................................................................................................................10-4
第 11 章: 报警......................................................................................................11-1
概述..........................................................................................................................11-1
配置报警..................................................................................................................11-2
报警分类................................................................................................................11-10Vijeo Citect 配置 手册发行版 2 v
将报警记录到打印机............................................................................................11-17
设备分组................................................................................................................11-18
显示报警................................................................................................................11-19
声音报警................................................................................................................11-29
将报警属性作为标签使用....................................................................................11-34
修改模拟量报警阈值............................................................................................11-36
第 12 章: 过程分析器..........................................................................................12-1
概述..........................................................................................................................12-1
趋势标签..................................................................................................................12-2
趋势历史文件..........................................................................................................12-6
什么是过程分析器？ ..............................................................................................12-7
过程分析器的属性..................................................................................................12-9
在过程分析器中显示标签....................................................................................12-10
趋势笔类型............................................................................................................12-11
更改过程分析器的属性........................................................................................12-17
其他数据源............................................................................................................12-32
数据导出................................................................................................................12-36
第 13 章: 页面管理..............................................................................................13-1
概述..........................................................................................................................13-1
菜单配置工具..........................................................................................................13-2
重新排序菜单项....................................................................................................13-12
“主页”按钮........................................................................................................13-15
第 14 章: 报表......................................................................................................14-1
概述..........................................................................................................................14-1
定义报表： ..............................................................................................................14-2
查看报表..................................................................................................................14-5
HTML 报表...........................................................................................................14-12
第 15 章: 累积器..................................................................................................15-1
概述..........................................................................................................................15-1
配置累积器..............................................................................................................15-2
累积器参数..............................................................................................................15-6
第 16 章: 安全......................................................................................................16-1
概述..........................................................................................................................16-1
计划工厂安全..........................................................................................................16-2
区域和权限..............................................................................................................16-3
分配权限和区域......................................................................................................16-4
添加用户记录..........................................................................................................16-5
限制对象的访问......................................................................................................16-9vi 版本 7.20 2011 年 10 月
管理工程中的身份验证........................................................................................16-14
对象安全性............................................................................................................16-17
工程安全性............................................................................................................16-20
操作系统的安全性................................................................................................16-23
运行管理器............................................................................................................16-24
Windows 键盘命令...............................................................................................16-25
第 17 章: 课程总结..............................................................................................17-1
概述..........................................................................................................................17-1
总结—Vijeo Citect 配置.........................................................................................17-2
课程评估..................................................................................................................17-3
深入培训..................................................................................................................17-4
考试..........................................................................................................................17-6
附录 A: CICODE 简介........................................................................................ A-1
概述........................................................................................................................... A-1
为何使用 Cicode？ .................................................................................................. A-2
附录 B: 多语言工程........................................................................................... B-1
概述........................................................................................................................... B-1
在 Vijeo Citect 中配置多语言功能........................................................................ B-2
附录 C: 深入练习............................................................................................... C-1
概述........................................................................................................................... C-1
练习........................................................................................................................... C-2
附录 D: 设计规范............................................................................................... D-1
概述........................................................................................................................... D-1
良好设计的意义....................................................................................................... D-2
过程控制硬件和通信............................................................................................... D-6
过程数据................................................................................................................... D-7
数据文件................................................................................................................... D-9
图形页面................................................................................................................. D-10
操作员命令............................................................................................................. D-14
操作员通知............................................................................................................. D-17
安全......................................................................................................................... D-18
附录 E: VIJEO CITECT 的故障排除 ................................................................. E-1
概述............................................................................................................................E-1
Vijeo Citect 知识库...................................................................................................E-2
联系支持....................................................................................................................E-4
